Design Shown
Top: Quartered Oak | Edge: Black | Paint: Black
5100 Series
Call for Price
Computer Table with Modesty Panel
- Practical computer table alternative
- Six standard sizes, largest 30”W x 72”L; custom sizes available
- Decorative leg panel matches top
- Modesty panel grommets standard
- Double C leg provides exception leg room clearance, table support
- 1 ¼” top available in HPL; 30 stocked selections plus custom options
Product Details
Barricks’ 5100 Series computer table’s six sizes provides a variety of work surface areas to meet your needs. The top is 1 1/8” particleboard core with high pressure laminate top surface and moisture resistant bottom surface with a protective t-mold or 3mm edge. The 5100 Series Double C leg consists of welded components: 1” x 2” 18 gauge steel base leg and two 1” x 2” 18 gauge steel vertical supports with 1” sq 18 gauge steel top bar. Steel modesty panel secures to legs. Leg laminated panel matches top. Adjustable levelers ensure proper positioning and alignment on uneven floors. Barricks stocks 30 HPL options to create your customized design.
5100 Series- 30″ Height
HPL Top Particleboard Core
| Size | T-Mold Model # | 3mm Model # | Weight |
| 24×30 | BK51-2430-PT | BK51-2430-PM | TBD |
| 24×48 | BK51-2448-PT | BK51-2448-PM | TBD |
| 30×36 | BK51-3036-PT | BK51-3036-PM | TBD |
| 30×48 | BK51-3048-PT | BK51-3048-PM | TBD |
| 30×60 | BK51-3060-PT | BK51-3060-PM | TBD |
| 30×72 | BK51-3072-PT | BK51-3072-PM | TBD |
Features & Options
T-mold Edge
Rounded Corners
Rounded plastic molding secures top’s edge using friction barb; provides impact protection to sides. T-mold edged tables have rounded corners.
3mm Edge
Square Corners
3mm (1/8”) thick flat plastic edging machine glued, sealing edge; provides impact protection to top’s sides. 3mm edged tables have square corners.
Double C Leg
Each leg has two welded 1” x 2” vertical supports; this provides exceptional weight bearing capacity.
Adjustable Levelers
Adjustable levelers provide stability on uneven floors and ensure proper height positioning to adjoining tables.
Options:
Specification & Materials
Top:
HPL Particle Board Core- 1 1/8″ th particleboard core with high pressure laminate (HPL) top surface, moisture resistant backer bottom surface finished with a protective edge option- t-mold or 3mm.
Edging:
T-mold- an extruded plastic edging in the shape of a “T”. The stem part is barbed and inserted into a slot in the core board. The friction barbs prevent the t-mold from coming out of the core. T-mold external surface is slightly rounded and provides protection against impacts to side. T-mold is an economical edge.
3mm- An extruded 3mm (1/8”) plastic that is machine glued to panel sides sealing edge, then machine trimmed to fit panel thickness. Edging provides protection against impact to sides. 3mm corners are square and more expensive than using T-mold.
Legs:
The 5100 Series Double C leg consists of welded components: 1” x 2” 18 gauge steel base leg and two 1” x 2” 18 gauge steel vertical supports with 1” sq 18 gauge steel top bar. Steel modesty panel secures to legs. Leg laminated panel matches top. Adjustable levelers ensure proper positioning and alignment on uneven floors.
Assembly
Need assembly PDF
Cut Sheet
